MNS2.0 low-voltage switchgear

MNS2.0 low voltage switchgear is a combination of low voltage switches authorized by ABB company.  It is a new type of low voltage distribution device designed by ABB, used for indoor three-phaseAC 50Hz (or 60Hz), rated voltage 400V power systems, as a means of energy distribution and centralized power control. It is applicable to all places where power is generated, distributed, such as auxiliary power cabinets,distribution cabinets, motor power supply and control centers, open-loop or closed-loop control system electronic cabinets, power systems, petrochemicals, industrial and mining enterprises, public utilities, municipal engineering, commercial buildings, etc.  The entire system fully considers the future development space and avoids the risk of being eliminated due to technological development,

energy distribution and centralized power control. It is applicable to all places where power is generated, distributed, such as auxiliary power cabinets,distribution cabinets, motor power supply and control centers, open-loop or closed-loop control system electronic cabinets, power systems, petrochemicals, industrial and mining enterprises, public utilities, municipal engineering, commercial buildings, etc.  The entire system fully considers the future development space and avoids the risk of being eliminated due to technological development,

Product features

1、The cabinet frame adopts a C-shaped skeleton with E=25mm modular holes. The frame structure can be assembled into various types of cabinets without the need for special tools, such as front operated and back-to-back single or multiple combination switchgear. The cabinet structure is compact and the layout is reasonable, which improves space utilization and reduces the limiting factors of on-site location.

2、The drawer unit is equipped with a working position, an experimental position, a withdrawal position, and an isolation position,each of which can be mechanically interlocked with the main switch and can be padlocked on the operating handle to ensure the strictness of operation and the personal safety of operators.

3、Adopted with standardized components, the entire series is standardized, making it convenient for maintenance personnel to carry out later maintenance.

4、Strong adaptability to rejection, customized to meet the protection level required for use according to customer needs.

5、Different forms of functional components (such as fixed and pull-out components) can be freely installed in a cabinet, making the combination more flexible The equipment operates continuously, with high fracture reliability, ensuring the personal safety of operators.

6、The equipment has good plasticity and is convenient for future optimization and renovation. Through multiple high-performance tests, the following projects have been completed.
